Camera
Afbeeldingsensor: 1/3" Progressive Scan CMOS
Max. Resolutie: 2688 × 1520
Min. Verlichting: Kleur: 0,001 Lux @ (F1.0, AGC AAN), Z/W: 0 Lux met IR
Sluitertijd: 1/3 s tot 1/100.000 s
Dag & Nacht: IR-filter
Hoekverstelling: Pan: 0° tot 360°, kantelen: 0° tot 90°, draaien: 0° tot 360°
Lens
Lens Type: Vaste brandpuntslens, 2,8 en 4 mm optioneel
Brandpuntsafstand & FOV
2,8 mm, horizontaal FOV 100,2°, verticaal FOV 54,7°, diagonaal FOV 119,7°
4 mm, horizontaal FOV 81,1°, verticaal FOV 44,7°, diagonaal FOV 94,6°
Lensmontage: M12
Iris Type: Vast
Diafragma: F1.0
Scherptediepte
2,8 mm: 1,9 m tot ∞
4 mm: 2,5 m tot ∞
DORI
2,8 mm: D: 63 m, O: 25 m, R: 12 m, I: 6 m
4 mm: D: 78 m, O: 31 m, R: 15 m, I: 7 m
Verlichting
Aanvullend Licht Type: IR
Aanvullende Lichtbereik
2I: tot 60 m; 4I: tot 80 m
Slim Aanvullend Licht: Ja
IR Golflengte: 850 nm
Video
Hoofdstream
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Derde stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Derde stream wordt ondersteund onder bepaalde instellingen.
Videocompressie
Hoofdstream: H.265/H.264/H.265+/H.264+
Sub-stream: H.265/H.264/MJPEG
Derde stream: H.265/H.264
*Derde stream wordt ondersteund onder bepaalde instellingen.
Videobitrate: 32 Kbps tot 8 Mbps
H.264 Type: Baseline Profile, Main Profile, High Profile
H.265 Type: Main Profile
Bitratecontrole: CBR, VBR
Schaalbare Video Codering (SVC): H.264 en H.265 codering
Regio van Interesse (ROI): 1 vaste regio voor hoofdstream en sub-stream
Netwerk
Protocollen:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP,
IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket,
WebSockets
Gelijktijdige Live-weergave: Tot 6 kanalen
API: Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
Gebruiker/Host
Tot 32 gebruikers. 3 gebruikersniveaus: administrator, operator en gebruiker
Beveiliging
Wachtwoordbeveiliging, ingewikkeld wachtwoord, HTTPS-encryptie, IP-adresfilter,
Beveiligingsauditlogboek, basis- en digest-authenticatie voor HTTP/HTTPS, TLS 1.1/1.2, WSSE
en digest-authenticatie voor Open Network Video Interface
Netwerkopslag
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR),
Samen met high-end Hikvision-geheugenkaarten worden geheugenkaartenversleuteling en
gezondheidsdetectie ondersteund.
Client: iVMS-4200, Hik-Connect, Hik-Central
Webbrowser
Plug-in vereiste live-weergave: IE 10, IE 11,
Plug-in vrije live-weergave: Chrome 57.0+, Firefox 52.0+, Edge 89+,
Lokale service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Afbeelding
Afbeeldingsparameters schakelaar: Ja
Afbeeldingsinstellingen:
Draaimodus, verzadiging, helderheid, contrast, scherpte, versterking, witbalans
instelbaar via clientsoftware of webbrowser
Dag/Nacht-schakelaar: Dag, Nacht, Auto, Schema
Brede Dynamische Bereik (WDR): 120 dB
SNR: ≥ 52 dB
Afbeeldingsverbetering: BLC, HLC, 3D DNR
Privacymasker: 4 programmeerbare polygonale privacymaskers
Interface
Ethernet Interface: 1 RJ45 10 M/100 M zelfadaptieve Ethernetpoort
On-Board Opslag: Ingebouwde geheugenkaartsleuf, ondersteunt microSD/microSDHC/microSDXC-kaart, tot 512 GB
Ingebouwde Microfoon: NVT
Ingebouwde Luidspreker: NVT
Audio: NVT
Alarm: NVT
Resettoets: Ja
Indicator: NVT
Evenement
Basisgebeurtenis:
Bewegingsdetectie (ondersteunt alarmtriggering door gespecificeerde doeltypes (mens en voertuig)), video-tampering alarm, uitzondering
Slim Evenement: Scèneverandering detectie
Deep Learning Functie
Gezichtsherkenning: Ja
Perimeterbescherming:
Lijnoverschrijding, inbraak, gebiedsintrede, gebiedsuitgang
Ondersteunt alarmtriggering door gespecificeerde doeltypes (mens en voertuig)
Algemeen
Stroom:
-2I: 12 VDC ± 25%, 0,6 A, max. 7,2 W, Ø 5,5 mm coaxiale voedingsplug, omgekeerde polariteit bescherming,
PoE: IEEE 802.3af, Class 3, max. 9 W;
-4I: 12 VDC ± 25%, 0,83 A, max. 10 W, Ø 5,5 mm coaxiale voedingsplug, omgekeerde polariteit bescherming,
PoE: IEEE 802.3af, Class 3, max. 12 W
Afmetingen: 286,7 mm × 93,1 mm × 91,2 mm (11,3" × 3,7" × 3,6")
Verpakkingsafmetingen: 386 mm × 156 mm × 155 mm (15,2" × 6,1" × 6,1")
Gewicht: Ongeveer 1085 g (2,4 lb)
Gewicht met verpakking: Ongeveer 1639 g (3,6 lb)
Opslagomstandigheden: -30 °C tot 60 °C (-22 °F tot 140 °F). Vochtigheid 95% of minder (niet-condenserend)
Opstart- en bedrijfsomstandigheden: -30 °C tot 60 °C (-22 °F tot 140 °F). Vochtigheid 95% of minder (niet-condenserend)
Goedkeuring
EMC
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
Veiligheid
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
Milieu
CE-RoHS: 2011/65/EU
Bescherming
IP67: IEC 60529-2013
AE-specifiek
Aantal infraroodlampen:
-2I: 2 infraroodlampen
-4I: 4 infraroodlampen
Vast diafragma: Ondersteund, F1.0
Focuscontrolmodi: Auto
ABF: Niet ondersteund
ICR-blauwe glasmodule: Niet ondersteund
Aansluitpaneel: Niet ondersteund
Schroefmateriaal: SUS304
